Maserati MCPura
Sonus faber High Premium sound system
Twelve speakers across the doors, centre and surrounds run from a 12-channel class D dual-DSP amplifier.
The whole system
Drag to turn. Positions are drawn by zone from the maker’s published layout; exact placement inside each zone is schematic.
- Speakers
- 12
- Amplifier
- 695 W
- Channels
- 12
- Rank by speakers
- 19 of 20
Engineering notes
- Sonus faber High Premium system: 12 speakers on 12 amplifier channels, 695 W, class-D with Dual DSP; the same system is used in MCPura Cielo and was developed for the MC20.
- Per-driver power: 45 W tweeters and surround units, 60 W midrange, 100 W woofers.
- Silk-dome tweeters, paper-cone midrange and neodymium magnets (lighter than the ceramic magnets in Sonus faber home speakers), behind metal grilles patterned like moving strings.
- pt.AUDIO says each speaker has its own class-D amplifier stage.
Cabin
- Layout
- Two-seat coupe
- Seats
- 2
- Zones with speakers
- 3
- silk dome tweeters
- paper cone midrange
- neodymium magnets
- metal string-pattern grilles
- die-cast aluminium amplifier chassis
More from Sonus faber
Sources
- sonusfaber.com/en/collaborations/maserati/mcpura
- a.storyblok.com/f/259299/2400x1350/b255151061/mcpura_coupe-system_wide.png
- audioxpress.com/news/sonus-faber-and-maserati-boast-luxury-and-innovation-in-new-mc20-spyder
- pursuitperfectsystem.com/sonus-faber-adapts-to-the-new-maserati-mc20-cielo/
- autos.yahoo.com/maserati-mc20-sound-system-impressive-133900690.html
- pt.audio/2020/09/11/the-maserati-mc20-and-its-sonus-faber-sound-system/
6 speakers: front-doors. 2 speakers: dash-center. 4 speakers: rear-pillars
